Minster 400 Ton HeviStamper Straight Side Mechanical Press

Minster 400 Ton HeviStamper Straight Side Mechanical Press

Sell Your MINSTER E2-400
(248)709-6723
brian@rygatellc.com
ConditionUsed
1 available
Sell Your MINSTER E2-400

Overview

Type:
Straight Side Mechanical Stamping Presses
Manufacturer:
MINSTER
Model:
E2-400
Year:
1986
Stock #:
710-02572
Status:
For Sale

Description

Minster 400 Ton HeviStamper Straight Side Mechanical Press, 96" x 48" Bed Area, 12" Stroke, 32" Shut Height, 0 - 70 SPM

Tonnage400 T362.874 t
Stroke12"304.8 mm
Shut Height32"812.8 mm
Bed area (Left to right)96"2,438.4 mm
Bed area (Front to back)48"1,219.2 mm
SPM min.0 strokes/min.0 strokes/min.
SPM max.70 strokes/min.70 strokes/min.
Adjustment6"152.4 mm
Windows Width31"787.4 mm

Model Number: E2-400-96-48
Bed Area: 96” x 48”
Slide Area: 96” x 48”
Stroke: 12”
Strokes per Minute: 0-70
Shut Height: 32” over bed
Shut Height: 25” over bolster plate
Bolster Plate: 7” thick t-slotted plate
Slide Adjustment: 6”
Windows: 32” wide approx..
Floor Standing

Air Clutch and Brake Assembly
Air Counterbalances
Hydraulic Tie Rod Nuts
Recirculating Lube System
T-Slotted Ram and Bolster
Dual Ross Valve
8 Point Gibbing
Floor Standing
Motors and Controls
Wintriss Smart Pac Press Control
Wintriss Resolver
Wintriss Die Protection
Floor Standing Console Mounted
AC Variable Speed Drive and Motor
