Komatsu 330 US Ton Straight Side Mechanical Press

Komatsu 330 US Ton Straight Side Mechanical Press

Sell Your KOMATSU E2P300W
(248)709-6723
brian@rygatellc.com
ConditionUsed
1 available
Sell Your KOMATSU E2P300W

Overview

Type:
Straight Side Mechanical Stamping Presses
Manufacturer:
KOMATSU
Model:
E2P300W
Condition:
Good
Year:
1980
Stock #:
710-02400
Status:
For Sale
Serial #:
1907037

Description

300 Ton Komatsu, E2P300W, 98.43" x 51.18" bed, 7.87" stroke, 30-60 SPM, 30.39" Shut Height, 55" wide window

Tonnage330 T299.371 t
Stroke7.87"199.9 mm
Shut Height30.39"771.91 mm
Bed area (Left to right)98.43"2,500.1 mm
Bed area (Front to back)51.18"1,300 mm
SPM min.30 strokes/min.30 strokes/min.
SPM max.60 strokes/min.60 strokes/min.
Adjustment8.66"219.96 mm
Windows Width55"1,397 mm
Dimensions146.4" LR x 82.6" FB146.4" LR x 82.6" FB
Weight100,000 # approx.100,000 # approx.

Capacity: 330 US Tons
Model Number: E2P300W
Year of Manufacture: 1980
Bed Area: 98.43” x 51.18”
Slide Area: 98.43” x 47.21”
Stroke: 7.87”
Adjustment: 8.66”
Shut Height: 30.39” SDAU
Strokes per Minute: 30-60
Windows: 55” wide approx..
Bolster Plate: 7” thick T-Slotted
Floor Standing

Air Clutch and Brake
Air Counterbalances
Recirculating Lube System
T-Slotted Ram and Bolster
T-Slots 6" Centers- Standard 1" T-Slots
8 Point Gibbing
Electrical Control Cabinet
Variable Speed Motor
Cieco Brake Monitor
Cieco Touchscreen Controller
Motors and Controls
Palm Buttons
Dual Ross Air Valve
Motorized Ram Adjustment
Main Motor Fwd./Reverse
