| Tonnage | 300 T | 272.156 t |
| Stroke | 12" | 304.8 mm |
| Shut Height | 37" | 939.8 mm |
| Bed area (Left to right) | 96" | 2,438.4 mm |
| Bed area (Front to back) | 54" | 1,371.6 mm |
| SPM max. | 30 strokes/min. | 30 strokes/min. |
| Adjustment | 6" | 152.4 mm |
| Windows Width | 38" | 965.2 mm |
| Dimensions | 19' 11" tall x 135" LR x 98" FB | 19' 11" tall x 135" LR x 98" FB |
| Weight | 100,000# | 100,000# |
Air Clutch and Brake
Air Counterbalances
Palm Buttons
Voltage: 480/60/3
Motors and Controls
Dual Ross Air Valve
Recirculating Lubrication System
Floor Standing
Floor to top of Bolster: 47"
Footprint Dimensions: 135" LR x 98" FB
Overall Height: 19'11" floor to top of motor
